UFx.py version 1.6 from 07/16/2018
Page 1 of 2
Created by user vjeran on 07/17/2018 14:26:00
SLAC Moving Stretched Wire Magnetic Field Measurement Summary
| Magnet ID : | BACKGROUND |
| Directory : | S:\magdata\LCLS-II\Phase Shifter\Calibration\126Gcm_+By\Final Results\Stretched Wire |
| Date : | 06-26-2018 |
| Time : | 10:32:00 - 11:36:58 |
| Operator : | VV |
| Project : | DUMMY |
| Device Type : | Phase Shifter |
| Run Number : | 1 |
| Data Type : | |
| Run Comment : | rewired; 126 Gauss*cm magnet (By positive) |
| gap | I1Y | I2Y | I1X | I2X |
|
- |
113.8 4.6 (5) |
23.2 0.6 (5) |
2.9 5.0 (5) |
1.1 1.3 (5) |
| integral | gap | -02.00;+00.00 | -01.00;+00.00 | +00.00;+00.00 | +01.00;+00.00 | +02.00;+00.00 |
| I1Y |
- |
100.5 25.4 (3) |
114.9 3.0 (3) |
108.9 2.0 (3) |
117.2 5.6 (3) |
113.6 1.9 (3) |
| I2Y |
- |
24.0 3.3 (3) |
21.7 1.3 (3) |
22.6 1.0 (3) |
24.0 0.5 (3) |
21.7 2.2 (3) |
| I1X |
- |
0.1 3.0 (3) |
4.5 4.9 (3) |
-3.2 9.7 (3) |
1.2 3.2 (3) |
1.2 6.6 (3) |
| I2X |
- |
-0.5 0.9 (3) |
-0.6 1.8 (3) |
-0.4 2.4 (3) |
0.5 2.7 (3) |
1.7 0.7 (3) |
| integral | gap | +00.00;-02.00 | +00.00;-01.00 | +00.00;+00.00 | +00.00;+01.00 | +00.00;+02.00 |
| I1Y |
- |
114.7 4.6 (3) |
110.9 6.0 (3) |
112.4 3.1 (3) |
113.3 4.9 (3) |
112.8 2.2 (3) |
| I2Y |
- |
22.3 1.5 (3) |
24.8 1.9 (3) |
23.9 2.6 (3) |
22.6 1.5 (3) |
22.4 0.8 (3) |
| I1X |
- |
3.5 1.0 (3) |
-10.0 14.1 (3) |
1.5 6.8 (3) |
-1.4 4.2 (3) |
1.9 1.6 (3) |
| I2X |
- |
-0.6 0.5 (3) |
1.2 0.8 (3) |
-8.5 7.9 (3) |
0.2 1.6 (3) |
0.8 1.8 (3) |
UFx.py version 1.6 from 07/16/2018
Page 2 of 2
Created by user vjeran on 07/17/2018 14:26:00
SLAC Moving Stretched Wire Magnetic Field Measurement Summary
| Magnet ID : | BACKGROUND |
| Directory : | S:\magdata\LCLS-II\Phase Shifter\Calibration\126Gcm_+By\Final Results\Stretched Wire |
