Quadrupole Magnet Checks			34Q-070
	Date:	Magnet:	Operator(s):
	7/12/2001	34Q-070	Michael Rogers
	Notes:
	Redo. Copied gap measurments from original survey.

Magnetic Fiducial Coordinates: (inches)
	Fiducial	Z	X	Y
	TB1	-6.3156	11.2440	16.2009
	TB2	6.3200	11.2503	16.2028
	TB3	-6.3050	-11.2419	16.2058	Offset:
	TB4	6.3502	-11.2492	16.2022	0.0000	inches
	TB5	-5.1610	-15.2032	-4.9264
	TB6	4.6437	-15.2036	-4.8520
	Description:
	Fiducial values based on the measured mechanical center line.

Quadrupole Mechanical Centerline Checks:

Mandrel Check (4 Positions):	X (in)	Y (in)
Position 1	0.0001	0.0000
Position 2	0.0009	-0.0004
Position 3	0.0008	-0.0011
Position 4	-0.0001	-0.0009

Mandrel Check (Position 1):	X (in)	Y (in)
Position 1 (1^st check)	-0.0001	0.0003
Position 1 (2^nd check)	0.0003	0.0007
Position 1 (3^rd check)	0.0004	0.0003
Position 1 (4^th check if necc)	NA	NA
Position 1 (5^th check if necc)	NA	NA

Quadrupole Gap Measurement Checks

Gap Measurements:
Upstream (in)	Downstream (in)
Loc 1: 1.024	Loc 1: 1.025
Loc 2: 1.024	Loc 2: 1.024

Approval __________________

Quadrupole Magnet Fiducialization Traveller

Approval must be obtained before removing the magnet from the test stand.

Magnetic Measurements Approval by – Jack Tanabe or Tony King.

Magnet Serial Number 34Q-070

IHEP Magnetic Measurements Operator: ____________ Date:_____________

Measured Magnetic Center Offset Dx =__________ mm Dy =___________ mm

Measured at: Integrated Field: ____________ T-m @ Current_____________ Amps

SLAC Magnetic Measurements Operator: ____________ Date:_____________

Measured Magnetic Center Offset Dx =__________ mm Dy =___________ mm

Measured at: Integrated Field: ____________ T-m @ Current_____________ Amps

Fiducialization:

Date: 7/12/2001 Ambient Temperature ______________ deg. C.

Operator(s) Michael Rogers

Comment
Redo. Copied gap measurments from original survey.

Fiducial – Measured Coordinates	z	x	y
	(in)	(in)	(in)
TB1	-6.3156	11.2440	16.2009
TB2	6.3200	11.2503	16.2028
TB3	-6.3050	-11.2419	16.2058
TB4	6.3502	-11.2492	16.2022
TB5	-5.1610	-15.2032	-4.9264
TB6	4.6437	-15.2036	-4.8520

(For x, y corrected coordinates, use SLAC data if available. If not, use IHEP data.)

Fiducial – Corrected Coordinates	z	x	y
	(in)	(in)	(in)
TB1
TB2
TB3
TB4
TB5
TB6

Check Measurements:

Rod	xmeasured	xnominal	ymeasured	ynominal
R1	10.4991	10.5 in	14.8064	14.8 in
R2	10.4965	10.5 in	14.8091	14.8 in
R3	-10.5024	-10.5 in	14.8063	14.8 in
R4	-10.5014	-10.5 in	14.8060	14.8 in

Cylinder at Different Positions

Position 1 (x,y)=(0,0)	x (in)	y (in)
Position 2	0.0007	-0.0005
Position 3	0.0006	-0.0011
Position 4	-0.0002	-0.0009

Approval __________________
