Quadrupole Magnet Checks			34Q-059
	Date:	Magnet:	Operator(s):
	6/21/2001	34Q-059	Michael Rogers
	Notes:

Magnetic Fiducial Coordinates: (inches)
	Fiducial	Z	X	Y
	TB1	-6.3030	11.2452	16.2051
	TB2	6.2986	11.2546	16.2075
	TB3	-6.3419	-11.2537	16.2014	Offset:
	TB4	6.3218	-11.2508	16.2036	0.0000	inches
	TB5	-5.1773	-15.2018	-4.9719
	TB6	4.6957	-15.2015	-4.8144
	Description:
	Fiducial values based on the measured mechanical center line.

Quadrupole Mechanical Centerline Checks:

Mandrel Check (4 Positions):	X (in)	Y (in)
Position 1	-0.0001	0.0019
Position 2	0.0004	0.0016
Position 3	0.0008	0.0013
Position 4	-0.0001	0.0008

Mandrel Check (Position 1):	X (in)	Y (in)
Position 1 (1^st check)	0.0011	0.0014
Position 1 (2^nd check)	0.0007	0.0019
Position 1 (3^rd check)	0.0005	0.0017
Position 1 (4^th check if necc)	NA	NA
Position 1 (5^th check if necc)	NA	NA

Quadrupole Gap Measurement Checks

Gap Measurements:
Upstream (in)	Downstream (in)
Loc 1: 1.024	Loc 1: 1.024
Loc 2: 1.023	Loc 2: 1.023

Approval __________________

Quadrupole Magnet Fiducialization Traveller

Approval must be obtained before removing the magnet from the test stand.

Magnetic Measurements Approval by – Jack Tanabe or Tony King.

Magnet Serial Number 34Q-059

IHEP Magnetic Measurements Operator: ____________ Date:_____________

Measured Magnetic Center Offset Dx =__________ mm Dy =___________ mm

Measured at: Integrated Field: ____________ T-m @ Current_____________ Amps

SLAC Magnetic Measurements Operator: ____________ Date:_____________

Measured Magnetic Center Offset Dx =__________ mm Dy =___________ mm

Measured at: Integrated Field: ____________ T-m @ Current_____________ Amps

Fiducialization:

Date: 6/21/2001 Ambient Temperature ______________ deg. C.

Operator(s) Michael Rogers

Comment

Fiducial – Measured Coordinates	z	x	y
	(in)	(in)	(in)
TB1	-6.3030	11.2452	16.2051
TB2	6.2986	11.2546	16.2075
TB3	-6.3419	-11.2537	16.2014
TB4	6.3218	-11.2508	16.2036
TB5	-5.1773	-15.2018	-4.9719
TB6	4.6957	-15.2015	-4.8144

(For x, y corrected coordinates, use SLAC data if available. If not, use IHEP data.)

Fiducial – Corrected Coordinates	z	x	y
	(in)	(in)	(in)
TB1
TB2
TB3
TB4
TB5
TB6

Check Measurements:

Rod	xmeasured	xnominal	ymeasured	ynominal
R1	10.4939	10.5 in	14.8151	14.8 in
R2	10.4985	10.5 in	14.8081	14.8 in
R3	-10.5026	-10.5 in	14.8101	14.8 in
R4	-10.5020	-10.5 in	14.8075	14.8 in

Cylinder at Different Positions

Position 1 (x,y)=(0,0)	x (in)	y (in)
Position 2	0.0005	-0.0003
Position 3	0.0009	-0.0005
Position 4	-0.0001	-0.0011

Approval __________________
