Sextupole Magnet Checks



 21S-25





















































Date:



Magnet:







Operator(s):









 10/29/2001



 21S-25







 Michael Rogers































Notes:























































































Magnetic Fiducial Coordinates: (inches)



























































Fiducial

Z

X

Y















TB1

-3.5138

 4.2203

 15.5072















TB2

 3.5111

 4.1988

 15.5058















TB3

-3.6174

-10.5034

 12.5369





Offset:









TB4

 2.2900

-10.5005

 12.5385





0.0000

 inches







TB5

-3.7343

-15.0623

 0.0146















TB6

 3.7666

-15.0620

 0.0473



























































Description:



















Fiducial values based on the measured mechanical center line.


























Sextupole Mechanical Centerline Checks:



Mandrel Check (4 Positions):

X (in)

Y (in)

Position 1

 0.0000

 0.0009

Position 2

-0.0015

-0.0011

Position 3

 0.0017

-0.0014

Position 4

 0.0023

-0.0027

Position 5

 0.0028

-0.0016

Position 6

 0.0016

-0.0019

Mandrel Check (Position 1):

X (in)

Y (in)

Position 1 (1st check)

 0.0020

 0.0009

Position 1 (2nd check)

 0.0023

 0.0008

Position 1 (3rd check)

 0.0040

-0.0006

Position 1 (4th check if necc)

NA

NA

Position 1 (5th check if necc)

NA

NA













Sextupole Gap Measurement Checks





Gap Measurements:



Upstream (in)

Downstream (in)

Loc 1: 1.072

Loc 1: 1.069

Loc 2: 1.073

Loc 2: 1.072

Loc 3: 1.069

Loc 3: 1.070

Approval ________________________






Sextupole Magnet Fiducialization Traveller

Approval must be obtained before removing the magnet from the test stand.

Magnetic Measurements Approval by – Jack Tanabe or Tony King.

Magnet Serial Number 21S-25

IHEP Magnetic Measurements Operator: ____________   Date:_____________

Measured Magnetic Center Offset  Dx =__________ mm  Dy =___________ mm

Measured at: Integrated Field:  ____________ T-m @ Current_____________ Amps

SLAC Magnetic Measurements Operator: ____________   Date:_____________

Measured Magnetic Center Offset  Dx =__________ mm  Dy =___________ mm

Measured at: Integrated Field:  ____________ T-m @ Current_____________ Amps

Fiducialization:

Date: 10/29/2001    Ambient Temperature ______________ deg. C.

Operator(s)  Michael Rogers

Comment


Fiducial – Measured

Coordinates

z

x

y

(in)

(in)

(in)

TB1

-3.5138

4.2203

15.5072

TB2

3.5111

4.1988

15.5058

TB3

-3.6174

-10.5034

12.5369

TB4

2.2900

-10.5005

12.5385

TB5

-3.7343

-15.0623

0.0146

TB6

3.7666

-15.0620

0.0473

(For x, y corrected coordinates, use SLAC data if available.  If not, use IHEP data.)

Fiducial – Corrected

Coordinates

z

x

y

(in)

(in)

(in)

TB1







TB2







TB3







TB4







TB5







TB6







Check Measurements:

Flat Center

xmeasured

xnominal

ymeasured

ynominal

Upstream



0.0 in



12.8 in

Downstream



0.0 in



12.8 in



Position 1 (x,y)=(0,0)

x (in)

y (in)

Position 2

-0.0015

-0.0021

Position 3

 0.0017

-0.0024

Position 4

 0.0022

-0.0036

Position 5

 0.0027

-0.0026

Position 6

 0.0015

-0.0028

Approval ________________________
