Sextupole Magnet Checks



 21S-21





















































Date:



Magnet:







Operator(s):









 1/24/2002



 21S-21







 Michael Rogers































Notes:























































































Magnetic Fiducial Coordinates: (inches)



























































Fiducial

Z

X

Y















TB1

-3.7390

 4.2164

 15.5096















TB2

 3.7790

 4.1946

 15.5076















TB3

-3.6412

-10.5466

 12.5120





Offset:









TB4

 2.2922

-10.4990

 12.5381





0.0000

 inches







TB5

-3.7447

-15.0617

 0.0222















TB6

 3.7523

-15.0620

 0.0209



























































Description:



















Fiducial values based on the measured mechanical center line.


























Sextupole Mechanical Centerline Checks:



Mandrel Check (4 Positions):

X (in)

Y (in)

Position 1

 0.0001

 0.0004

Position 2

 0.0007

 0.0011

Position 3

 0.0002

 0.0008

Position 4

 0.0023

-0.0020

Position 5

 0.0027

-0.0009

Position 6

 0.0013

-0.0020

Mandrel Check (Position 1):

X (in)

Y (in)

Position 1 (1st check)

 0.0026

 0.0003

Position 1 (2nd check)

 0.0024

-0.0002

Position 1 (3rd check)

 0.0024

 0.0005

Position 1 (4th check if necc)

NA

NA

Position 1 (5th check if necc)

NA

NA













Sextupole Gap Measurement Checks





Gap Measurements:



Upstream (in)

Downstream (in)

Loc 1: 1.071

Loc 1: 1.072

Loc 2: 1.070

Loc 2: 1.069

Loc 3: 1.071

Loc 3: 1.069

Approval ________________________






Sextupole Magnet Fiducialization Traveller

Approval must be obtained before removing the magnet from the test stand.

Magnetic Measurements Approval by – Jack Tanabe or Tony King.

Magnet Serial Number 21S-21

IHEP Magnetic Measurements Operator: ____________   Date:_____________

Measured Magnetic Center Offset  Dx =__________ mm  Dy =___________ mm

Measured at: Integrated Field:  ____________ T-m @ Current_____________ Amps

SLAC Magnetic Measurements Operator: ____________   Date:_____________

Measured Magnetic Center Offset  Dx =__________ mm  Dy =___________ mm

Measured at: Integrated Field:  ____________ T-m @ Current_____________ Amps

Fiducialization:

Date: 1/24/2002    Ambient Temperature ______________ deg. C.

Operator(s)  Michael Rogers

Comment


Fiducial – Measured

Coordinates

z

x

y

(in)

(in)

(in)

TB1

-3.7390

4.2164

15.5096

TB2

3.7790

4.1946

15.5076

TB3

-3.6412

-10.5466

12.5120

TB4

2.2922

-10.4990

12.5381

TB5

-3.7447

-15.0617

0.0222

TB6

3.7523

-15.0620

0.0209

(For x, y corrected coordinates, use SLAC data if available.  If not, use IHEP data.)

Fiducial – Corrected

Coordinates

z

x

y

(in)

(in)

(in)

TB1







TB2







TB3







TB4







TB5







TB6







Check Measurements:

Flat Center

xmeasured

xnominal

ymeasured

ynominal

Upstream



0.0 in



12.8 in

Downstream



0.0 in



12.8 in



Position 1 (x,y)=(0,0)

x (in)

y (in)

Position 2

 0.0006

 0.0007

Position 3

 0.0001

 0.0005

Position 4

 0.0022

-0.0024

Position 5

 0.0026

-0.0012

Position 6

 0.0012

-0.0024

Approval ________________________
